Cisco DNA Traffic Telemetry Appliance

Item #: 6226635   |   Model #: DN-APL-TTA-M

  |   10 Questions
$19,356.30
$19,356.30
Sold out

1 Each

Special Buy
Add to list
Cisco DNA Traffic Telemetry Appliance
Type Value
Additional Information
  • Default Memory: 16-GB DRAM
  • Processor: Integrated in the chassis: Intel 1.8GHz Quad Core Processor
  • Network and management I/O:
    • Supported connectors:
      • One RJ-45 10/100/1000 management Ethernet port
      • One RJ-45/RS-232 compatible console port
      • One Mini-USB serial console port
      • One RJ-45/RS-232 compatible auxiliary port
      • Two USB 2.0 connectors
  • Gigabit Ethernet ports:
    • Yes: Six 1G SFP ports
  • 10 Gigabit Ethernet port:
    • Yes: Two 10G SFP+ ports
    • Note: Built-in 10G ports cannot be reduced to 1G speed.
  • Network interface module: Yes, Only for SSD cards
  • Wall-mounting: No
  • External USB flash memory: 1-GB USB flash-memory support
  • Redundant power supply: Yes: Dual power supplies by default; option of either AC or DC power supply
  • Power input:
    • Worldwide ranging AC input range (85 to 264 VAC)
    • Worldwide ranging DC (-40 to -72V; 48V nominal)
  • Power consumption:
    • Maximum (DC): 242W
    • Maximum (AC): 250W
    • Maximum (out): 250W
  • Airflow: Front to back
  • Operating temperature (nominal): 32 to 104°F (0 to 40°C)
  • Operating temperature (short-term): 32 to 122°F (0 to 50°C)
  • Operating humidity (nominal) (relative humidity): 10% to 85%
  • Operating humidity (short-term): 5% to 90%
  • Storage temperature: -40° to 150°F (-40° to 70°C)
  • Storage humidity: (relative humidity) 5% to 95%
  • Operating altitude: -500 to 10,000 feet (-152 to 3048 meters)
  • Network Equipment Building Standards (NEBS): GR-1089 and GR-63
  • EMC standards:
    • FCC 47 CFR Part 15 Class A
    • VCCI Class A
    • AS/NSZ Class A
    • CES-003 Class A
    • EN55022/CISPR 22 Information Technology Equipment (Emissions)
    • EN55024/CISPR 24 Information Technology Equipment (Immunity)
    • EN300 386 Telecommunications Network Equipment (EMC)
    • EN50082-1/EN61000-6-1 Generic Immunity Standard
  • Safety Standard:
    • UL60950-1
    • CSA C22.2 No. 60950-1-03
    • EN 60950-1
    • IEC 60950-1
    • AS/NZS 60950.1
Application/Usage Network Monitoring
Brand Name Cisco
Depth 18.2"
Form Factor Rack-mountable
Height 1.7"
Manufacturer Cisco Systems, Inc
Manufacturer Part Number DN-APL-TTA-M
Manufacturer Website Address http://www.cisco.com
Marketing Information The Cisco DNA Traffic Telemetry Appliance is a telemetry sensor platform that is used to generate telemetry from mirrored IP network traffic and share it with Cisco DNA Center for application and endpoint analytics. Network traffic is received from switches and routers via Switched Port Analyzer (SPAN) mirroring and fed into the Cisco DNA Traffic Telemetry Appliance mirroring interfaces. The appliance analyzes the received traffic to produce a telemetry stream for Cisco DNA Center that is sent via the appliance's network interface.

The platform supports 20-Gbps sustained forwarding data traffic through the chassis and comes in a 1-RackUnit (1RU) form factor. The appliance has six built-in 1-Gbps Small Form Factor (SFP)-only interfaces (these do not support SFP+), and two built-in 10-Gbps Enhanced SFP (SFP+) interfaces (these support only the 10-Gbps rate) that support Synchronous Ethernet (SyncE). The device comes with one copper Ethernet 10/100/1000 Mbps network management port and supports storage extension through the network interface module (NIM) slot.

Features and benefits

The Cisco DNA Traffic Telemetry Appliance complements endpoint and application analytics solutions on Cisco DNA Center. The fixed, 1RU form factor and Cisco IOS® XE software-based device management make it an easy fit into existing network deployments. Cisco DNA Center manages the appliance in a manner similar to the way it manages network devices such as switches and wireless devices.
Product Model DN-APL-TTA-M
Product Name DNA Traffic Telemetry Appliance
Product Type Network Monitoring Appliance
Weight (Approximate) 25 lb
Width 17.3"
